MIMO Mesh Network XK-m504e

The broadband mimo mesh networking is a mobile broadband multimedia communication system designed with the new concept of “wireless grid network”. The system with powerful functions and excellent performance; All nodes can realize real-time interaction of multi-channel voice, data, image and other multimedia information by adopting distributed network architecture without central AD hoc network under the condition of non-line-of-sight and fast movement. Supports any network topology, such as point-to-point, point-to-multipoint, chain-like relay, mesh network and hybrid dynamic topology.

The network adopts the same frequency networking and multi-hop relay. Each node device can move quickly and randomly, and the network topology can be changed and updated quickly without affecting the network transmission.The whole network is convenient to deploy, flexible to use, simple to operate and easy to maintain. It can provide users with reliable, timely, efficient and secure full IP clear voice, broadband data, high-definition video and visual command and scheduling and other multimedia integrated services under complex application scenarios such as fast movement and non-line-of-sight shielding.

The broadband self-organizing network can be widely used in the military, public security, armed police, fire protection, civil air defense, electric power, petroleum, mining, transportation, water conservancy, forestry, radio and television, medical, water and air communications and other sectors, providing users with reliable, timely, Rich integrated services such as safe and efficient voice, data, video and visual command and dispatch can meet users’ wireless broadband communication needs in normal or emergency situations to the greatest extent, and truly achieve “anytime, anywhere on demand”.

Product Features and Functions

• Product Features
• Decentralized, self-organizing network;
• Immunity to interference and multipath effects;
• Easy to deploy, flexible to use, and simple to operate;
• Outstanding dynamic networking capabilities;
• Strong ability to adapt to complex environments;
• Supports basic configuration and device information checks via the web UI.
• MIMO technologies such as time-division, spatial diversity, and spatial multiplexing.
• Product Features
• Operating frequency range: 70 MHz to 6 GHz (customizable), FHSS hopping;
• Adjustable bandwidth, supporting 2.5 MHz, 5 MHz, 10 MHz, and 20 MHz (optional);
• Supports up to 256 nodes on the same frequency;
• Supports multicast and broadcast services;
• Enhanced operating modes such as intelligent frequency selection and adaptive frequency hopping;
• Data encryption: Supports various channel encryption methods, including AES-128, AES-256, and EDS;
• Flexible networking;
• Supports multiple serial ports;
